| Technology | Microwave y doble PIR tipo cortina con Antimasking |
| Microondas | 24 GHz / Adjustable |
| PIR lens | 2 zones |
| Detection range | 3 m / 35o |
| Frequency | 868 MHz Jeweller with Ajax transmitter included |
| Transmission distance | ? 1200 m in open space |
| Masking | Available |
| Tamper-resistant opening | Available |
| LEDs indication | Alarm |
| DIP Switch configuration | Antimasking, AND/OR function, impulse counter (1 or 2), Microwave and LEDs |
| Wired outputs | Alarm, tamper and transmitter power supply |
| Power | 1 battery ER14505 3.6V |
| Consumption | Minimal consumption (Rest: 30 uA / Maximum: 20 mA) |
| Temp. operation | -20 oC ~ 50 oC |
| Degree of protection | IP54 |
| Dimensions | 295 (H) x 37 (W) x 32 (D) mm |
| Weight | 150 g |
