| Brand | Sunell |
| Range | TPC4107KV |
| Thermal sensor | VOx FPA non-refrigerated |
| Thermal sensor resolution | 384x288 |
| Pixel Size | 17µm |
| Lens | 35mm |
| Thermal sensitivity | ?40mK |
| Range of Detectable Temperatures | -20oC up to 150oC |
| Temperature Accuracy | ±8oC |
| Spectral range | LWIR 8~14µm |
| Compression | H.265 / H.264 / MJPEG |
| Viewing angle | 10o x 8o |
| Focus | Fixed lens, no focus |
| Intelligent functions | Temperature detection and alarm, human detection and vehicle detection |
| Temperature measurement | Supports 3 rule types (Point, Area and Line) |
| DRI Ranges | Human: 1028m (D), 257m (R), 129m (I)Vehicle: 3157m (D), 789m (R), 395m (I) |
| VCA ranges | Person detection: 350mVehicle detection: 400mFire detection (object 1x1m): 1029mFire detection (object 0.2x0.2m): 206mTemperature Measurement (object 0.2x0.2m)): 82mTemperature Measurement (object 1x1 |
| Audio | 1 IN / 1 OUT |
| Alarm | 2 In / 2 Out |
| Internal memory | Micro SD card up to 256GB |
| Network interface | Ethernet 10M/100M BaseT |
| Remote access | WEB interface, CMS (SunView), Smartphone and NVR |
| Interoperability | ONVIF & Private Protocol |
| Power | 12VDC/4.5W, PoE IEEE802.3af |
| Temp. operation | -40oC~+60oC |
| Degree of protection | Weatherproof IP66 |
| Material | Metallic |
| Dimensions | O120.5mm × 315.9mm ~ 352.6mm |
| Weight | 1620 g |
| Certificates | NDAA / CE / FCC |
