| Brand | Sunell |
| Inputs for IP cameras | 32 channels |
| IP compatible cameras | KIT-PANDA-BLACKBODY, Sunell, ONVIF |
| Video outputs | 1 HDMI 4K, 1 VGA simultaneous |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 / MPEG4 |
| Main display resolution | 1CH 12Mpx, 4CH 8Mpx, 8CH 4Mpx, 16CH 1080p, 32CH 720p |
| Auxiliary display resolution | 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768 (60 Hz) |
| Recording resolution | 12MP/8MP/6MP/5MP/3MP/1080P/720P/D1 |
| Audio inputs | 1 Line IN |
| Audio outputs | 1 Line OUT |
| Bidirectional audio | Does not have |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Facial Recognition | Maximum 20 faces/second Up to 32CH with Face RecognitionStorage 16 Booklets with up to 10.000 faces Detection of strangers: The matching level can be set manually Searches by: Comparison type, Image s |
| Smart functions | Facial Recognition |
| POS Function | Does not have |
| Alarms | 2 IN / 1 OUT |
| Total bandwidth | 320 Mbps input (128Kbps ~ 8Mbps per channel) |
| Recording method | Manual, programmed (Continuous, Motion Detection, Video Loss ... ) |
| Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Internal memory | 4 SATA 3.5" HDD up to 12 TB (not included)HDD performance analysis with Seagate Skyhawk AI Surveillance series |
| Communication | 1 x USB 3.0 / 2 x USB 2.0 / 1x eSATA / 1 x RS485 / 1 x RS232 / 1 x RJ45 10/100/1000Mbps (Ethernet) |
| POE Interface | 16 x RJ45 100Mbps IEEE 802.3af, max. 160W |
| Remote access | Web Browser, Smartphone App and CMS Software |
| Power | AC 100~240 V, 15 W (WITHOUT HDD) |
| Operating temperature | -10° ~ +50° C |
| Dimensions / weight | 70 (H) x 368 (W) x 440 (D) mm / 4.2 Kg |
