| Brand | Sunell |
| Range | SN-D2P |
| Thermal sensor | VOx FPA non-refrigerated |
| Thermal sensor resolution | 256x192 |
| Pixel Size | 12µm |
| Thermal lens | 2mm |
| Thermal sensitivity | ?60mK |
| Detectable temperature range | -20oC - 150oC y 0oC - 500oC |
| Temperature Accuracy | ±2oC / ±2oC |
| Spectral range | LWIR 8~14µm |
| Compression | H.265 / H.264 / MJPEG |
| Thermal viewing angle | 90o x 65o |
| Focus | Fixed lens, no focus |
| Visible sensor | 1/2.8" 2MP STARVIS CMOS |
| Visible sensor resolution | 1600x1200 |
| Minimum visible sensor illumination | Colour: 0.05Lux @(F2.2, AGC ON), B/W: 0.005Lux @(F2.2, AGC ON), 0Lux with IR |
| Visible lens | 2.3mm |
| Visible angle of view | 100o x 75o |
| Illuminator | White light0.3m distance: 0.8×0.8m 1m distance: 1.8×1.2m |
| Intelligent functions | Temperature measurement, fire detection (thermal sensor) and smoke and flame detection (visible sensor) |
| Temperature measurement | Supports 3 rule types (Point, Area and Line) |
| Temperature measuring ranges | Temperature Measurement (object 0.1x0.1m)): 3m |
| Audio | Microphone included |
| Alarm | 1 In / 1 Out |
| Internal memory | Micro SD card up to 512GB |
| Network interface | Ethernet 10M/100M BaseT |
| Remote access | WEB interface, CMS (SunView), Smartphone and NVR |
| Interoperability | ONVIF (Profile S/T/G/M) & Private Protocol |
| Power | 12VDC/3W, PoE IEEE802.3af |
| Temp. operation | -30oC~+60oC |
| Degree of protection | IP67 |
| Reliability | Surge protection: 6 kV, Air discharge: 8 kV, Contact discharge: 8 kV |
| Shock resistance | 25 g (IEC60068-2-29) |
| Vibration resistance | 2 g (IEC 60068-2-6) |
| Material | Metallic |
| Dimensions | 55mm × 118mm x 36mm |
| Weight | 440 g |
| Certificates | CE / FCC |
