| Brand | Safire |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 BNC channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | Default: 8 Channels from BNC and 8 (replacement) + 8 (extra) IP Channels (up to 5Mpx) |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Video / audio compression | H.265 / H.264 |
| Display resolution | HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768BNC × 1 : CVBS |
| BNC input resolution | TVI/ AHD/CVI: 5MP/4MP/1080p Lite/720P/WD1 |
| Main Stream coding | 5MP Lite@10fps, 4MP Lite/1080P@12fps(PAL)/15fps(NTSC)1080P Lite/ 720P/WD1/D1@25fps (PAL)/30fps (NTSC) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Bit rate | 32Kbps ~4Mbps |
| Bandwidth | 32 Mbps (Incoming) / 60 Mbps (Outgoing) |
| Alarms | Does not have |
| Recording method | Manual, scheduled, smart events |
| Backup | USB / Network |
| Internal memory | 1 HDD SATA 3.5" of up to 10TB (not included) |
| Communication | 2 x USB 2.0 (Mouse and backup) / RJ45 (Ethernet) |
| RS 485 | 1 x RS 485 (half-duplex) |
| Remote access | Web Browser, Safire Smartphone App and Safire Smart VMS software |
| Power | DC 12 V / 2 A (Consumption without HDD < 8 W) |
| Dimensions / weight | 42 (H) x 255 (W) x 222 (D) mm / 1.2 Kg |
