| Brand | Safire Smart |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 8 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | Default: 8 Channels from BNC and 8 (substitution) +2 (extra) IP channels (up to 5Mpx)) |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Video / audio compression | H.265 / H.264 |
| Display resolution | HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
| BNC input resolution | TVI/AHD/CVI:1080P/1080P Lite/720P/720P Lite/WD1 |
| Main Stream coding | Channel 1: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC)Other channels: 1080P Lite/720P/WD1: 12fps (PAL)/15fps (NTSC)720PLite: 25fps(PAL) / 30fps(NTSC)IP channel: 25fps(PAL) / 30fps (NTSC) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Bit rate | 32Kbps ~4Mbps |
| Bandwidth | 16 Mbps (Incoming) / 60 Mbps (Outgoing) |
| Alarms | Does not have |
| Recording method | Manual, programmed, exception, motion, intelligent events |
| Backup | USB / Network |
| Internal memory | 1 HDD SATA 3.5" of up to 8TB (not included) |
| Communication | 2 x USB 2.0 (Mouse and backup) / RJ45 10/100M(Ethernet) [%VAR%] |
| Remote access | Web Browser, Safire Smartphone App and Safire Smart VMS software |
| Power | DC 12 V / 1.5 A (Consumption without HDD) |
| Dimensions | 42 (H) x 255 (W) x 222 (D) mm |
