| Capacity | 1TB |
| Interface | SATA |
| Transfer Rate | 6 Gb/s |
| Model | WD10PURX |
| Manufacturer | Western Digital |
| Buffer size | 64 MB |
| Temp. operation | 0o C ~ +65o C |
| Brand | Safire Smart |
| Range | I1 |
| Image sensor | 1/3" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2592x1520) |
| Minimum illumination | Colour: 0.005 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR range | 50 m |
| Day/Night | Removable mechanical ICR filter |
| Electronic Shutter | 1/2~1/100.000 s |
| Main Stream rate | 25 FPS (4Mpx, 2K, 3Mpx, 1080P, 720P) HFR mode: 60 FPS (1080P / 720P) |
| Extra Stream rate | 25 FPS (720P, D1, CIF, 480x240) |
| Third stream rate | 25 FPS (D1, 480x240, CIF) |
| Compression | H.265+ / H.265 / H.264+ / H.264 |
| Bitrate | 64 Kbps ~ 8 Mbps |
| Lens | 2.8~12mm motorised lens |
| Viewing Angle (FOV) | H: 100-28.9°, V: 54.5-16.7°, D: 104.8-33.1° |
| Range performance | W: 59 m (D), 24 m (O), 12 m (R), 6 m (I)T: 206 m (D), 82 m (O), 41 m (R), 21 m (I) |
| Image improvements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection | Yes |
| Smart Features | Advanced artificial intelligence based on human, vehicle and non-motorized vehicle classification on: Area Intrusion, Line Crossing, Entry Region, Exit RegionFace Detection and Face CaptureCounting of |
| Audio | Built-in microphone, 1 Input |
| Audio Compression | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT |
| Internal memory | MicroSD card up to 256GB |
| Remote access | Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability | ONVIF |
| Power | DC 12 V / 792qwsaa mA / 9.5 W max. / IEEE802.3af PoE |
| Degree of protection | Weatherproof IP67 |
| Material | Metallic |
| Temp. operation | -30o C ~ +60o C |
| Dimensions | 131 (?) x 99.60 (H) mm |
| Weight | 670 g |
| Range | B2 |
| Inputs for IP cameras | 8CH IP |
| IP compatible cameras | Safire Smart (native protocol), ONVIF |
| Bidirectional audio | 1 input / 1 RCA output |
| Main stream recording | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
| Decoding capacity | 1CH 12Mpx @ 20FPS4CH 1080P @ 30FPS |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 |
| Audio Compression | G.711(U/A) |
| Total bandwidth | 80 Mbps downstream / 80 Mbps upstream |
| Video outputs | 1 HDMI 4K / 1 VGA |
| Display resolution | HDMI: 3840x2160@30FPS, 1920x1080, 1280x1024, 1024x768VGA: 1920x1080, 1280x1024, 1024x768*HDMI and VGA can be configured to output the same or a different video source |
| Yesmultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Multi-Screen | Main output: 1 / 4 / 6 / 8 / 9 (Live view)Secondary output: 1 / 4 / 6 / 8 / 9 (Live view)AI mode (Default): Max. 8CH (simultaneous HDMI and VGA) AI on recorder availableIndependent video output: Max. |
| Recording method | Manual, programmed, motion detection, smart events, alarm input, POS |
| POS Function | Si |
| Perimeter Protection | Need to use Safire Smart cameras with artificial intelligenceArtificial Intelligence based on the classification of humans, vehicles and two-wheeled vehicles on:- Area intrusion- Line crossover- Regio |
| Facial Recognition | Face detection with Safire Smart cameras 4I1 or 8I2 up to 8CH (All channels)Face detection by the NVR itself with any camera up to 2CHFacial recognition up to 6CH maxComputation of up to 18 images / s |
| Video metadata | Need to use Safire Smart 4I1 or 8I2 camerasHuman and vehicle feature extractionFor humans: Can extract up to 13 features (glasses, color of clothes, etc.)For vehicles: can extract up to 5característic |
| License plate recognition | Yes (Safire Smart license plate camera required) |
| Dewarping | Supports Fisheye camera dewarping |
| Alarms | 8 inputs / 4 outputs |
| External Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Internal memory | 1x 3.5" HDD SATA3.0 up to 10 TB (not included) |
| Communication | 1 x USB 3.0 / 2 x USB 2.0 / 2 x RJ45 10/100/1000M (Ethernet) / RS485 |
| Remote access | Web Browser, Safire Smartphone App and PC Software Safire Smart VMS |
| Power | DC 12V / 2A, ? 20W (Without hard disk) |
| Operating temperature | -10oC ~50oC, Humidity 10~90% |
| Dimensions / weight | 48.1 (H) x 300 (W) x 248.5 (D) mm / 1.18 Kg |
