| Brand | Raythink |
| Range | PD2 |
| Thermal sensor | 256x192 VOx uncooled 12µm |
| Spectral range | LWIR 8 ~ 14µm ~ [%VAR%] |
| Thermal sensitivity | ?40mK (@25°C,F#1.0,25Hz) |
| Optical sensor | 1/2.8" CMOS 5Mpx |
| Lens | 10mm (term.) / Motorized Autofocus 5.4~108mm (opt.) 20X |
| Pan/Tilt Range | Horizontal: 360° continuous, Vertical: 0° ~ +90° |
| Manual speed | Horizontal: 0.1°~ 120°/s, Vertical: 0.1°~ 60°/s |
| Intelligent functions | Fire detectionIntrusion detection: line crossing, area entryHuman/vehicle classification by AI |
| Temperature range | -20oC~550oC |
| Temperature Accuracy | ±2oC / ±2% |
| Temperature measurement | Supports up to 4 measurement rules: full screen, dot, line, area |
| Audio | 1 input / 1 output / speaker included |
| Alarm | 2 inputs/ 1 outputs |
| Internal memory | Micro SD card up to 256GB (not included) |
| Network interface | 1x Ethernet 10/100M BaseT |
| Others | RS485 |
| Interoperability | ONVIF, SDK |
| Power | 12VDC / 20W |
| Temp. operation | -40oC~+70oC |
| Degree of protection | Weatherproof IP66 |
| Dimensions | 265 × 147.5 × 248.7 |
| Weight | 2.5 kg. |
