| Brand | Raythink |
| Range | PC6 |
| Thermal sensor | 1280x1024 VOx uncooled 12µm |
| Spectral range | LWIR 8 ~ 14µm ~ [%VAR%] |
| Thermal sensitivity | ?40mK (@25°C,F#1.0,25Hz) |
| Optical sensor | 1/1.8" CMOS 4Mpx |
| Main Stream rate | 2688×1520, 1920×1080, 1280×720 (25ips) visible1280×1024, 1280×720, 1024×768 (25ips) thermal |
| Extra Stream rate | 1920×1080, 1280×720, 704×576, 352×288 (25ips) visible640×512, 384×288 (25ips) thermal |
| Compression | H.265 / H.264 / MJPEG |
| Lens | Motorized Autofocus 30~150mm (therm.) 5X / Motorized Autofocus 6~300mm (vis.) 50X |
| Angle | Horizontal: 28.7o~5.9o (term.) / H: 62o~1.6o (opt.) |
| Pan/Tilt Range | Horizontal: 0°~360° (without end), Vertical: -90°~+90° |
| Manual speed | Horizontal: 0.01°~120°/s, Vertical: 0.01°~60°/s |
| Detection ranges | Human detection (1.8x0.5 m): 6.3KmDetection of vehículo(4x1.4 m): 19.2KmHuman Recognition (1.8x0.5 m): 1.6KmVehicle recognition (4x1.4 m): 4.8KmPerson ID (1.8x0.5 m): 0.8KmVehicle identification (4x1 |
| Intelligent functions | Fire detectionIntrusion detection: line crossing, area entrySynchronized zoom |
| Audio | 1 Input / 1 Output |
| Alarm | 7 inputs / 2 outputs |
| Internal memory | Micro SD card up to 256GB (not included) |
| Network interface | 1x Ethernet 10/100M BaseT |
| Others | RS485 |
| Interoperability | ONVIF, SDK |
| Power | 48VDC / 200W |
| Temp. operation | -40oC~+70oC |
| Degree of protection | Weatherproof IP66TVS 6000V lightning protection |
| Dimensions | 598mm x 738mm x 468mm (width x height x depth) |
| Weight | 48Kg. |
