| Interface | 4 ports RJ45 10/100/1000 Mbps + 2 SFP Ports |
| Port speed | 4 x 10/100/1000 Mbps - 2 x SFP Gigabit |
| PoE | Port 1 802.3bt 1~4 802.3af/at Ports |
| Power supply | Up to 180W PoE on all ports.Up to 90 W port 1 Up to 30 W port (1~4)If the device is powered from 46vDC to 57vDC, it can power up to IEEE 802.3af.If the device is powered from 50vDC to 57vDC, it can po |
| PoE features | According to IEEE standard 802.3at PoE+ / IEEE 802.3af PoE / IEEE 802.3bt (Type2)PoE++ [%VAR%] |
| VLAN | Up to 4094Port-based Vlan |
| Redundancy control | ERPS (only available on its SFP ports) |
| Network Protocols and Technologies | DHCP SnoopingJumbo Frame 10000Loop PreventionFlow controlStorm control (unicast,broadcast,multicast)SPAN |
| Management Protocols | Web/Cloud/APP |
| Installation | DIN rail and/or wall |
| Power | Power supply not included46-57VDC / 4,2A Reference is recommended:- RG-NIS-PA120-54 (will offer lower Total PoE Power)- RG-NIS-PA240-54 |
| Protections | 6KV against voltage spikesInput power protection 4KV/2KV [%VAR%]IP40 against dustEMC Level 4 |
| Operating temperature | -40oC~65oC In enclosed space-40oC~75oC With airflow |
| Recommended Industrial SFP Modules | RG-NIS-GE-SFP-10KM-SM1310RG-NIS-GE-SFP-20KM-SM1310-BIDIRG-NIS-GE-SFP-20KM-SM1550-BIDIRG-NIS-GE-SFP-550M-MM850 |
| Dimensions | 500 x 430 x 195mm |
| Weight | 1,08 Kg (With packaging) |
