| Size | 4 Rack units |
| Expansion Slot | 3 card slot RG-M7000 |
| Management Level | L3 |
| Interfaces | Up to 144 RJ45 ports 10/100/1000 MbpsUp to 144 ports SFP10/100/1000 MbpsUp to 48 SFP+ 10Gigabit ports*The purchase of one or more RG-M7000 cards is required and, depending on the cards chosen, the int |
| Switching Capacity | 480Gbps |
| MAC Table | Up to 32K |
| ACL | Up to 1900 rules |
| Reshipment Rate | 360Mbps |
| VLAN | Up to 4096Voice VLANPort-Based VLANMAC-Based VLANIP-Based VLAN |
| Redundancy control | Spanning Tree (STP, RTSP)RLDP |
| Network Protocols and Technologies | LLDP/LLDP-MEDIGMP Snooping v1/v2/v3CPU Protect PolicyEnergy Efficient EthernetACLJumbo Frame 9216SNMP802.1XRIPOSPFDHCP ServerDHCP Snooping |
| Cluster Technology | Virtual Cluster Switching |
| Management Protocols | Web/Cloud/APP |
| Power | 2 Redundant power supply slot. Compatible:RG-PA300I-FS (AC 300W))RG-PA460I-FS (AC 460W))(Power supply not included) |
| Operating temperature | 0° C - 50° C |
| Cooling | 1 Slot for ventilation module. Compatible:NBS7003-FAN |
| Weight | 9,6 Kg (With packaging) |
| Dimensions | 442 mm x 313 mm x 175 mm 4U |
