| Interface | 48 Ports RJ45 + 4 Ports SFP28 + 2 QSFP+ Ports + MGMT Port + Console Port + USB Port |
| Port speed | 48 x 100/1000/2.5G/5GBASE-T + 4 x 1/10Gb SFP+ + 4 x 10/25Gb SFP28 |
| VLAN | Up to 4096 802.1Q / Port-based / Private VLAN / GVRP / Super VLAN / Basic QinQ |
| Switching Capacity | 840 Gbps |
| Reshipment Rate | 625 Mbps |
| MAC Table | 32K |
| ARP Table | 16K |
| Routers Table | 16K IPv4 + 16K IPv6 (unicast) 4000 IPv4 + 2000 IPv6 (multicast) |
| PoE features | Ports from 1 to 48 are PoE/PoE+ compliantPorts from 1 to 24 are PoE++ compliant (90W) |
| Total PoE Power | The equipment does not include power supplyPower supply RG-PA600I-P-F 400W (880 W with dual 200V AC to 240V AC power supply)Power supply RG-PA1000I-P-F 800W (1600 W with dual 200V AC to 240V AC power |
| Redundancy control | STP, RSTP, MSTP, LACP, ERPS |
| Protocol Management | Web/Cloud/APP, SNMP, CLI, RMON, Telnet, CWMP |
| Aggregation | 128 LACP ports 802.3ad |
| DHCP | Server / Client / Snooping / Relay / IPV6 Snooping / Ipv6 Client / IPSv6 Relay |
| Routing | Static / RIP / RIPng / OSPFv2 / OSPFv3 / IS-ISv4 / IS-ISv6 / BGP4 / BGP4+ / ECMP |
| ACL | Standard and Extended ACLs |
| QoS | 8 priorities per port: SP, WRR, DRR, SP+WRR, SP+DRR, RED/WRED |
| Multicast | IGMP v1/v2/v3 / IGMP proxy / IGMP v1/v2/v3 snooping / IGMP filtering / IGMP immediate leave / PIM-DM / PIM-SM / PIM-SSM / MLD Snooping v1/v2 / MLDv1/v2 / MSDP / PIM-SMv6 / PIunM-SSMv6 |
| Security | AAA / RADIUS / TACAS+ / 802.1x / SSH v1,v2 / IP Source Guard / CPP and NFPP / SAVI / Port Protection / RPF |
| High availability and virtual stacking | VSU technology that allows virtualization of multiple devices into a virtual one / REUP / ERPSUp to 2 units |
| Consumption | Without PoE < 200W, With PoE < 1800W |
| Operating temperature | 0° C - 45° C |
| Redundant fans | Included 3 unit for 3 Slot |
| Power supply | Not included, 2 Slot supports redundancy 1+1. Hot-swappable. Minimum 1 Unit of RG-PA600I-P-F or RG-PA1000I-P-F is required |
| Dimensions | 563 x 563 x 210mm |
| Power | AC 100 V - 240 V |
| Weight | 6,11 Kg |
