| Interface | 24 PoE Ports RJ45 + 4 SFP+ Ports 1 MGMT Port + 1 Console Port + 1 USB Port |
| Port speed | 24 Ports 10/100/1000Mbps + 4 Ports 10Gb |
| Switching Capacity | 128 Gbps |
| Reshipment Rate | 96 Mpps |
| MAC Table | 32K |
| ARP Table | 4K |
| Routers Table | 8K IPv4 + 4K IPv6 (unicast) 2500 IPv4 + 1200 IPv6 (multicast) |
| PoE features | 24 PoE/PoE+ Ports 802.3af/at |
| Total PoE Power | The equipment does not include power supplyWith power supply RG-PA600I-P-F 370W With power supply RG-PA1000I-P-F 740W |
| VLAN | Up to 4096 802.1Q / Port-based / Private VLAN / GVRP / Super VLAN |
| Redundancy control | STP / RSTP / MSTP / LACP / RLDP / ERPS |
| Protocol Management | Web/Cloud/APP, SNMP, CLI, RMON, GRPC |
| DHCP | Server / Client / Snooping / Relay / IPV6 Snooping / Ipv6 Client / IPv6 Relay /ND |
| Routing | IPv4/IPv6 static routing, RIP, RIPng, OSPFv2, OSPFv3, IS-ISv4, ISv4, and IS-ISv6, BGP4, BGP4+, [%VAR%] Routing policy |
| ACL | Standard and Extended ACL / MAC based / IPv6 / Redirection / Time based |
| QoS | 8 priorities per port: SP, RR, WRR, DRR, SP+WRR, SP+DRR, SP+DRR, SP+WFQ, RED/WRED, Traffic policing: CAR, 802.1p DSCP/ToS traffic |
| QinQ | QinQ Basic / QinQ Flexible |
| Multicast | IGMP v1, v2, v3 / IGMP Proxy / IGMP v1, v2, v3 Snooping / IGMP Filtering / PIM-DM / PIM-SM / PIM-SSM / MLD Snooping v1,v2 / MLD v1,v2 / PIM-SMv6 and PIM-SSM v6 / MSDP |
| Security | AAA / RADIUS / TACAS+ / 802.1x / SSHv1,v2 / IP Source Guard / CPP and NFPP / Port Protection |
| High availability and virtual stacking | VSU / ERPS / REUP / VRRP Technology |
| Operating temperature | 0° C - 45° C |
| Consumption | Without PoE < 65W, With PoE < 810W |
| Power supply | Not included, 2 Slot supports redundancy 1+1. Hot-swappable. Minimum 1 Unit of RG-PA600I-P-F or RG-PA1000I-P-F is required |
| Power | AC 100 V - 240 V |
| Dimensions | 442 x 420 x 43.6 mm |
