| Brand | Ruijie |
| Wireless Standard | Wi-Fi 6E 802.11ax |
| Frequencies | 2.4 GHz, 5GHz and 6GHz |
| Wi-FI performance | Up to 5375 MbpsRadio1: 2.4GHz 2x2 MU-MIMO - 574 MbpsRadio2: 5GHz 2x2 MU-MIMO - 2402 Mbps Up to 160MHzRadius 3: 6GHz 4x4 MU-MIMO - 4804 Mbps Up to 160MHz |
| Integrated antenna | 2.4GHz: 4,3dBi5GHz: 4,1dBi6GHz: 4,3dBi |
| Interfaces | 1 Port RJ45 Combo 100/1000/2500/5000Mbps PoE In1 SFP Combo Port 1000/2500/5000Mbps1 Port RJ45 IoT 10/100/1000Mbps with passive PoE Out 48v/12,95W1 Console Port |
| SSID | Up to 45 (15 per radio) |
| Operating modes | FIT: Adopted by Centralized AP Controller WSFAT: Standalone mode - Local Web AccessCloud: Managed through Ruijie Cloud |
| Security | WPA / WPA2 (AES) / WPA-PSK / WPA3-Personal (SAE) / WPA3-Personal mixed mode, WPA3-Enterprise / WPA3-OWE / WPA3-OWE mixed |
| Management | Web/Cloud/APP/Console |
| Technologies | Hidden SSIDBand SteeringLoad balancing based on number of users or trafficBandwidth ControlPPSK authentication (Proprietary) and 802.1XRogue AP DetectionIsolation between Wi-Fi clientsCPU Protection P |
| Compatible Hardware Controller | Series Controllers RG-WS6000 |
| Power | Jack connector 54Vdc/1,1AIt is recommended to power the device with Hi-PoE 802.3btIf powered with PoE+ 802.3at the AP will work properly but will not be able to power other devices through the LAN2 Io |
| Operating temperature | -10 °C ~ 50 °C |
| Dimensions | 230 x 230 x 51 mm |
| Weight | 1,25 Kg |
