| Brand | Reyee |
| Wireless Standard | Owner |
| Mode of operation | Point to Point / Point - Multipoint (up to 32 CPE) |
| Port RJ45 | 10/100/1000 Mbps |
| Frequencies | 5GHz – 5.85 GHz |
| Distance | Up to 15 km |
| Channel width | 20/40/80Mhz |
| Transmission range | 0 to +26 dBm |
| Integrated antenna | 23 dBi Dual directional |
| TDMA | Fixed Mode / Flexible Mode |
| Management | Configuration via web interface, One-click configuration, AI Heatmap for Bridge, Bridge Alignment Tool, Spectrum Scan and Link Optimization |
| Additional functionalities | SSID Masquerading, Spectrum Analysis, Alignment Tools, One-Touch Pairing, WMM, Storm Control, VLAN Packet Transmit, DHCP Server, Network Diagnoses Ping/TraceRoute/Dns, ARQ |
| Power | 24 VDC non-standard PoE |
| Operating temperature | -40 °C ~ 70 °C (When using power adapter the maximum operating temperature of the device and power adapter is 60o max) |
| Electrostatic Protection | ±24 kV Contact/Air |
| Surge protection | 6 kV |
| Degree of IP Protection | IP65 |
| Power consumption | < 12 W |
| Dimensions (Diameter x Length incl. mounting kit) | 368.5 x 271 mm |
| Weight | 2.33 Kg |
