| Brand | Queclink |
| Model | GL320MG |
| Installation | Portable and optional magnetic holder |
| Operating band | Cat M1:LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18 B19/B20/B25/B26/B27/B28/B66/B85Cat NB2:LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85 |
| LTE data transmission | eMTC (DL) 588 KbpseMTC (UL) 1119 KbpsNB2 (DL) 127 KbpsNB2 (UL) 158.5 KbpsNB1 (DL) 32 KbpsNB1 (UL) 70 Kbps |
| Frequency | 850/900/1800/1900 MHz |
| EGPRS data transmission | GPRS: 107Kbps (DL) / 85.6Kbps (UL)EDGE: 296Kbps (DL) / 236.8Kbps (UL) |
| GNSS type | U-blox all-in-one GNSS receiver |
| Sensitivity | Autonomous: -147 dBmHot start: -156 dBmReconnection: -160 dBmOn the move: -162 dBm |
| Positioning accuracy (CEP) | Autonomous: < 2.5m |
| TTFF (open field) | Cold start: 27 seconds approxIntermediate start: 27 seconds approxHot start: 1 second approx |
| Dimensions | 77.9(LA) x 39.9(AN) x 26.7(AL) |
| Weight | 93g |
| Backup battery | Lithium polymer, 2600 mAh |
| Battery Life | No report - 480 hoursReporting each 5min - 260 hoursReporting each 10min - 300 hours |
| Water resistance | IPX5 compatible |
| Charging voltage | 5VDC |
| External battery voltage | 3.7V to 4.2V DC |
| Working temperature | -20oC ~ +60oC |
| Message buffer | Up to 10000 messages |
| Digital inputs | x1 positive trigger input for ignition detectionx1 input to negative for normal use |
| Power button | On/Off button, allows remote deactivation |
| Function button with vibration | Emergency alert with immediate geo-fence configuration |
| Cellular antenna | Internal only |
| GNSS Antenna | Internal only |
| LED indicators | CEL, GNSS, PWR |
| USB Type-C interface | To load device and configuration |
| Transmission protocols | TCP, UDP, SMS |
| Scheduled reports | Positioning and status based on time intervals, distance, mileage or combination of these parameters |
| Geo-fence | Geo-fence and parking alarm, supports up to 20 regions |
| Low battery alarm | Warns when the backup battery is low |
| Ignition report | Reports when the device is turned on |
| SOS Report | SOS panic button alarm |
| Messages | Buffer to 10000 messages |
| Remote control | OTA control over digital outputs |
The GL320MG is used for a wide range of applications requiring real-time location awareness, such as private investigations, package delivery, temporary vehicle tracking, long-distance transportation, drag racing and animal management. High battery life.
