| Power supply input | 230VAC |
| Output voltage | 22~27.6VDC |
| Efficiency | 87% |
| Output current | Nominal: 42AMaximum: 5A (5 minutes)Middle charging current: 0.8A |
| Back-up battery | Supports up to 2x12VDC / 17Ah |
| Permitted cable | Up to 2.5mm2 |
| Protections | SCP, OLP, OVP, UVP, tamper - opening of the box |
| Materials | Plate DC01, 1mm, RAL3001 (red), made of metal |
| Closing | Lock (1xMR027, of the same code) |
| Degree of protection of the enclosure | IP30 |
| Dimensions | 385 x 402 x 88 [+/-2 mm]] |
