| Model | NVS-IPC-DOORVIEW1 |
| Resolution | HD 2MP / 1080P |
| Image sensor | CMOS / Supports automatic white balance, automatic gain control and automatic backlight compensation |
| Lens | Angle of view 120° (diagonal) / Focal length 2.2mm |
| Screen | 4.3" TFT LCD |
| Video transmission | Primary flow 1024*720/15fps, Secondary flow 640*360/15fps |
| System | Lite OS |
| Standby time | About 4 months (Wake 10 times a day, 30S each time) |
| Day and night conversion | Automatic switching of double filters |
| Infrared distance | Infrared 850 nm, effective distance 5 m |
| Network configuration method | QR code distribution network + sound wave + WiFi fast connection |
| Internet connection | WIFI802.11b/g/n 2.4Ghz |
| Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P |
| PIR human detection | Supports PIR detection |
| Audio Codec | WAV |
| Audio | Yes |
| Speaker | Yes |
| Detections | Automatic recording + event recording |
| Application | Tuya Smart App |
| Battery | 5000 mAh lithium battery - 5V/2A |
| Operating temperature | -10oC ~ +50oC |
| Humidity | <80%RH |
| Dimensiones | 120mm x 90mm x 25mm |
| Peso | Mirilla 75 gPantalla 203 g |
