| Hardware | CPU: Quad-core 1.3 GHz, 64-bit ARM Cortex-A35Memory: 512 MB DDR4 RAMFlash: 8 GB eMMCSupport 1x Micro SD |
| Antennas | 1x External Lora Antenna N-Female ConnectorInternal Wi-Fi Antenna |
| Channels | 8 |
| Connected devices | 2000 end devices |
| Frequency band | 868 MHz |
| Sensitivity | 140dBm@292bps |
| Power Output | 27dBm Max. |
| Protocol | V1.0 A-Class / B-Class / C-Class and V1.0.2 A-Class / B-Class / C-Class |
| Ethernet | 1x RJ45 10/100/1000Mbps Base-T (IEEE 802.3)Full or Half-Duplex mode with auto-detectionAuto MDI/MDIX |
| Wifi | IEEE 802.11 b/g/n |
| WiFi Transmission Power | 802.11b: 18 dBm +/-2.0 dBm (11 Mbps)802.11g: 15 dBm +/-2.0 dBm (6 Mbps)802.11g: 15 dBm +/-2.0 dBm (54 Mbps)802.11n@2.4 GHz: 14 dBm +/-2.0 dBm (MCS0_HT20)802.11n@2.4 GHz: 14 dBm +/-2.0 dBm (MCS7_HT20)8 |
| Network Protocols | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS,HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, MQTT, etc. |
| VPN Tunnel | OpenVPN/IPsec/PPTP/L2TP/GRE/DMVPN |
| Access Authentication | CHAP/PAP/MS-CHAP/MS-CHAPV2 |
| Firewall | ACL/DMZ/Port mapping/MAC binding/URL filtering |
| Management | Web, CLI, SMS, On-Demand Phone Access, Hub, Milesight IoT Cloud |
| Reliability | WAN failover |
| Integrated functions | Watchdog, RTC, Timer |
| Power | 5V/2A Type-C / PoE 802.3af, ? 4,2Max. |
| Operating temperature | -20oC to 60oC (Relative humidity <95%) |
| Temperatura de almacenamiento | -40oC a 85oC |
| Aislamiento ethernet | 1.5kV RMS |
| Grado de protección | IP65 |
| Dimensiones | 110 x 75 x 24 mm |
| Montaje | Escritorio o pared |
