| Brand | Milesight |
| Image sensor | 1/1.8" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2688z1520) |
| Main Stream rate | 60fps@(2688x1520, 2304x1296, 1920x1080, 1280x720) |
| Extra Stream rate | 60fps@(704x576, 640x480, 640x360, 352x288, 320x240) |
| Rate 3rd Stream | 30fps@(1280x720, 704x576, 640x480, 640x360, 320x240) |
| Compression | H.265+ / H265 / H.264+ / H264 / MJPEG |
| Bitrate | 16 Kbps ~ 16 Mbps (CBR / VBR) |
| Lens | 8~32mm Motorised auto-focus |
| FOV | H: 44°~13°; V: 25o~7o; D: 51°~15° |
| IRIS Control | Auto/Manual |
| Minimum illumination | Colour: 0.002Lux@F1.6B/W: 0 Lux with IR ON |
| Infrared Light | 100 m |
| Day / Night | Day / Night / Auto / Customizable / Programmable |
| Image improvements | Super WDR (120 dB), BLC, HLC, 2D DNR, 3D DNR, Defog Function, AWB, EIS, IP Address Filtering, AGC, Anti Flicker, Hall Mode, Deblur, Watermarking |
| ROI | Up to 8 Areas |
| License plate recognition | Up to 4 detection zonesMaximum speed for detection: 120 Km/hDetection up to 95m during the day and 45m during the night with IR activated |
| Intelligent traffic detection | License Plate Recognition, License Plate Color Recognition, Vehicle Type Classification, Vehicle Color Recognition, Vehicle Direction Recognition and Traffic Flow Detection |
| List of license plates | Allowed / Not Allowed / Visitors(max. 20000 license plates) to activate different actions |
| Detection of traffic violations | Detection of vehicles without license platesDetection of improper parkingDetection of oncoming traffic |
| Traffic statistics | Statistical summary of the flow of vehicles |
| Trigger Event | Motion Detection, License Plate List, Exceptions, Alarm Entry |
| Event Action | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL |
| Internal memory | MicroSD card, Max 1TB (required for LPR function) |
| Alarms | 1/1 |
| Audio | 1/1 |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Two-way Audio | Support |
| Audio bit rate | 16~256Kbps |
| SIP/VoIP | Yes. Voice and video over IP |
| Communication Interface | Ethernet 10/100M BaseT | 1 RS485 |
| Remote access | Web Browser, Smartphone App and Milesight Central Management System Software |
| Interoperability | API, HTTP, TCP, ONVIF Profile (G, M, S & T) |
| Certification | NDAA |
| Power | DC 12 V / MAX 8W (13W with IR ON), PoE+ IEEE802.3at |
| Degree of protection | Waterproof IP67, Vandal resistant IK10, Over voltage 4000V |
| Temp. operation | -40o C ~ +60o C |
| Dimensions | 171 (W) X 134 (H) X 320 (D) mm |
| Weight | 1623 g |
Milesight LPR cameras capture license plates with high accuracy, even at night or at high speed, detecting vehicles up to 120 km/h. Ideal for access control in municipalities, housing developments, highways or urban areas, they offer artificial intelligence to identify make, color, type of vehicle, license plate color and address. Its technology enhances safety, facilitates traffic management and optimizes road control.
