| Hardware | CPU: Dual-core [%RAR%] [%RAR%] Xtensa® [%RAR%]Memory: 8 MB PSRAMFlash: 16 MB |
| Antennas | 1x External LoRa antenna connector1x External LTE antenna (shared with GPS)1x External Wi-Fi Antenna |
| Channels | 8 |
| Connected devices | 2000 end devices |
| Frequency band | 868 MHz |
| Sensitivity | 140dBm@292bps |
| Power Output | 27dBm Max. |
| Protocol | V1.0 A-Class / B-Class / C-Class and V1.0.2 A-Class / B-Class / C-Class |
| Wifi | IEEE 802.11 b/g/nAP mode (device configuration only) |
| 4G LTE | 4G LTE (CAT 1)) 1x Nano SIM Slot |
| Bands 4G | LTE-FDD: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/66LTE-TDD: B34/38/39/40/41;GSM: B2/3/5/8 |
| Power | 1. Solar or DC (12~24 VDC) through the M12 connector2. Backup batteries of 3,6 V and 25000 mAh3. USB Type-C 5 V/2A |
| Battery duration | Up to 4 days with no sunlight |
| Consumption | 0.8W |
| Operating temperature | -30oC to 70oC (Relative humidity < 95%)) |
| Charging temperature | -20oC to 50oC |
| Storing temperature | -40oC to 85oC |
| Protection Grade | IP67 |
| Dimensions | 46 (D) x 157.5 (H) x 250 (W) mm |
| Mounting | Wall or Post |
| Other | 1x Reset button1x Console Port Type-C Connector |
| Certificates | CE, FCC |
