| Technology | LoRaWAN® |
| Frequency band | 868 MHz |
| Power Output | 16dBm Max. |
| Sensitivity | -137 dBm |
| Mode | OTAA/ABP Class A |
| Detection parameter | RMS current |
| Sampling frequency | 3.3kHz |
| Measuring frequency | 50~60 Hz |
| Maximum measured current | 100 A |
| Minimum current | 1 A |
| Accuracy | ±1 % (>5Arms), ±3 % (? 5Arms) |
| Resolution | 1 mA |
| Power | Directly from the measured cable om via USB Type-C |
| Operating temperature | -20oC ~ 70oC |
| Degree of protection | IP30 |
| Dimensions | 86.5 × 31 × 37.4 mmMeasuring clamp: ? 16 mm |
| Installation | CT clamp: suspended in the test driver Transmitter: flange mounting (in integrated mode) |
