| Brand | Milesight |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Resolution | 5 Megapixel (2592x1944) |
| Main Stream rate | 25fps@(2592x1944), 25fps@(2048x1536),25fps@(1920x1080, 1280x960, 1280x720, 704x576) |
| Extra Stream rate | 25fps@(704x576, 640x480, 640x360, 352x288,320x240) |
| Rate 3rd Stream | 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240) |
| Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Bitrate | 16 Kbps ~ 16 Mbps (CBR / VBR Adjustable) |
| Lens | varifocal 5.3~64mm (Optical Zoom 12X)) |
| Digital zoom | 16 X |
| FOV | H57°~H4°/D69°~D5°/V44°~V1° |
| Pan Range | 360o Manual: 0.1° ~50° /s | Default Speed: 50°/s |
| Tilt Range | -45°~30° Manual: 0.1° ~25°/s [%VAR%] | Default speed: 25°/s |
| Preset positions | 348 preset, 4 auto pattern, 8 auto tour, auto pan, auto scan |
| PTZ Control | Through network access |
| IRIS Control | Auto |
| Minimum illumination | Colour: 0.008Lux@F1.6B/W: 0Lux with IR on |
| Infrared lighting | 140 m |
| Day / Night | Day / Night / Auto / Customizable / Programmable |
| Image improvements | Super WDR PRO (120 dB), BLC, HLC, 2D DNR, 3D DNR, Defog Function, AWB, EIS, IP Address Filtering, AGC, Anti Flicker, Corridor Mode, Watermarking |
| ROI | Up to 8 Areas |
| Intelligent analysis | Motion Detection, Line Crossing, Loitering Detection, Region Entry, Region Exit, Object Left, Object Removed |
| Face detection | Real-time face detection |
| People Counting & Reporting | People counting at entrances and exits. Supports up to 4 people counting regions |
| Trigger Event | Motion Detection, Exceptions, Alarm Inputs |
| Event Action | Upload Image to FTP, SMTP, MicroSD Card, Enable Alarm Output, SIP Phone, HTTP Notification |
| Communication Interface | Ethernet Port 1*RJ45 10M/100M |
| Internal memory | MicroSD card, Max 256 GB |
| Alarms | 1/1 |
| Audio | 1/1 |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Two-way Audio | Support |
| Audio bit rate | 16~256Kbps |
| SIP/VoIP | Support. Voice and Video over IP |
| Remote access | Web Browser, Smartphone App, Milesight Central Management System Software and Milesight Enterprise Software |
| Interoperability | ONVIF (G/Q/S/T Profile) |
| Power | DC 12 V / 2.0 A / 20 W, PoE+ IEEE802.3at |
| Temp. operation | -40o C ~ +60o C |
| Degree of protection | IP66 |
| Dimensions (without bracket) | 172 (H) x 218 (D) x 120 (W) mm |
| Weight (without bracket) | 2000 g |
