| Brand | Milesight |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Main Stream rate | 50fps@(1920x1080, 1280x960, 1280x720, 704x576) |
| Extra Stream rate | 50fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) |
| Rate 3rd Stream | 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180) |
| Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Bitrate | 16 Kbps ~ 16 Mbps (CBR / VBR Adjustable) |
| Lens | 2.8mm. |
| FOV | H111° / D128° / V61° (2.8mm) |
| Minimum illumination | Colour: 0.005Lux@F1.6B/W: 0Lux with IR ON |
| Infrared Light | 50m. |
| Day / Night | Day / Night / Auto / Customizable / Programmable |
| Advanced features | Super WDR PRO (140 dB), BLC, HLC, 2D DNR, 3D DNR, defog, AWB, IP address filtering, AGC, anti-flicker, corridor mode, debur |
| ROI | Up to 8 Areas |
| Intelligent analysis | Advanced motion detection, line crossing, loitering detection, region entry, region exit, object left, object removed |
| People counting and reporting | Counting of people entering and exitingUp to 4 detection areas for people counting per area |
| Trigger Event | Motion Detection, Exceptions, Alarm Inputs |
| Event Action | Upload Image to FTP, SMTP, MicroSD card, enable alarm output, SIP call, HTTP notification |
| Communication Interface | Ethernet Port 1*RJ45 10M/100M |
| Audio | Built-in microphone |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio bit rate | 16~256Kbps |
| SIP/VoIP | Yes. Voice and video over IP |
| Internal memory | Supports local storage on microSD/SDHC/SDXC card, up to 1TB |
| Remote access | Web browser, smartphone App and software Milesight Central Management System, Milesight VMS Enterprise |
| Interoperability | ONVIF (G/Q/S/T Profile) |
| Power | PoE (802.3af) |
| Consumption | 6W MAX (with IR ON) |
| Degree of protection | Weatherproof IP67 - IK10 |
| Temp. operation | -40oC~+60oC |
| Dimensions | 108mm. (O) x 96.5mm. |
| Weight | 600g. |
