| Brand | Jade Bird |
| Type | High power siren |
| Operating voltage | DC 16 - 30 V |
| Connection | JBE communication bus 2-hilos, without polarityPower supply 24V DC to 2-hilos (required) |
| Wired | Twisted pair without mesh 0.5 - 2.5 mm2 |
| JBE bus consumption Bus consumption 24V DC | ? 0.25 mA @24 V? 50 mA @24 V; ? 1.2 W @24 V (active) |
| Sound pressure level | 100 dBA @1 m; 1-2 kHz Swept Tone (0.25 Hz) |
| Working temperature | -10? ~ +55? |
| Storage Temperature | -20 to +60oC |
| ENVIRONMENT | ? 95% RH (without condensation or ice formation) |
| Address | Addressing tool JBE-AT1 |
| Address range | 1-200 |
| Dimensions (OxH) | O100 × 67 mm |
| Weight | 0.1 kg (including base) |
| Protection Grade | IP31 |
| Compatible base | JBE-2165 |
| Certified | EN 54-3:2001EN 54-3:2001/A1:2002EN 54-3:2001/A2:2006 |
