| Brand | InfiRay |
| Range | SD4 |
| Thermal sensor | 640x512 VOx uncooled 12µm |
| Spectral range | LWIR 8 ~ 14µm ~ [%VAR%] |
| Thermal sensitivity | ?40mK (@25°C,F#1.0,25Hz) |
| Optical sensor | 1/1.8" CMOS 4Mpx |
| Lens | 50mm (term.) / Motorized Autofocus 6.5~240mm (opt.) 37X |
| Pan/Tilt Range | Horizontal: 360° continuous, Vertical: -27° ~ +90° |
| Manual speed | Horizontal: 0.1°~ 200°/s, Vertical: 0.1°~ 120°/s |
| Wiper | Auto-wiper |
| Intelligent functions | Fire detectionIntrusion detection: line crossing, area entryHuman/vehicle classification by AI |
| Temperature range | -20oC~550oC |
| Temperature Accuracy | ±2oC / ±2% |
| Temperature measurement | Supports up to 4 measurement rules: full screen, dot, line, area |
| Audio | 1 Input / 1 Output |
| Alarm | 7 inputs / 2 outputs |
| Internal memory | Micro SD card up to 256GB (not included) |
| Network interface | 1x Ethernet 10/100M BaseT |
| Others | RS485 |
| Interoperability | ONVIF, SDK |
| Power | 24VDC / 48W |
| Temp. operation | -40oC~+70oC |
| Degree of protection | Weatherproof IP66 |
| Dimensions | ?250 × 413 mm. |
| Weight | 8.0 kg. |
