| Brand | ThermTec |
| Thermal sensor | 640x512 VOx |
| Spectral range | 8 ~ 14um |
| Optical sensor | 1/1.8" Sony CMOS |
| Main Stream rate | 640x512 (25fps) (Therm) / 2560x1440 (25fps) (Opt) |
| Extra Stream rate | CIF (25fps)(Term) / D1, VGA, 640x360, CIF, QCIF, QVGA (25fps) (Opt) |
| Compression | H.265 / H.264 / MJPEG |
| Lens | Motorized Autofocus 30 ~ 150 mm (Term) 5X / Motorized Autofocus 10.5 ~ 945 mm (Opt) 90X |
| Angle | H: 20.6o - 4.15o (Therm) / H: 24.55o - 2.77o (Opt) |
| Pan/Tilt Range | Horizontal: 0°~360° (without end), Vertical: -45° ~ 45° |
| Manual speed | Horizontal: 0.01° ~ 25°/sec, Vertical: 0.01° ~ 15°/sec |
| Preset positions | 256 preset |
| Thermal sensitivity | ?40mK |
| Range of Detectable Temperatures | -20 ? to 150 ? ( from -4 ? to ? 302 ) |
| Accuracy | ± 8oC / ±2% |
| Image improvements | Defog, Privacy Masking, Mirror, ROI, 3D DNR, BLC, HLC |
| VCA ranges | Human detection (1.8x0.5 m): 4410 mDetection of vehículo(4x1.4 m): 20290 mHuman Recognition (1.8x0.5 m): 1100 mVehicle recognition (4x1.4 m): 5070 mPerson ID (1.8x0.5 m): 550 mVehicle identification ( |
| Intelligent functions | High temperature alarm, Motion detection, |
| Audio | Does not have |
| Alarm | 2 outputs |
| Internal memory | Micro SD card up to 64GB |
| Network interface | 1x Ethernet 10/100M BaseT |
| Others | RS 485, CVBS output |
| Remote access | WEB interface, VMS and NVR |
| Interoperability | ONVIF, SDK |
| Power | 24 ADC, 12VDC / 30W |
| Temp. operation | -25o C ~ +55o C |
| Degree of protection | Weatherproof IP66 |
| Dimensions | 373 (D) x 400 (W) x 434 (H) mm |
| Weight | 50 Kg |
