| Brand | Hikvision |
| Range | SOLUTIONS |
| Image sensor | 1/1.8" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Main Stream rate | 25 fps (2688×1520, 2560x1440, 1920×1080, 1280×720) [%VAR%] |
| Extra Stream rate | 25 fps (1920×1080, 1280×760, 704×576, 325×288) [%VAR%] |
| Third stream rate | 25 fps (1280×760, 704×576, 325×288) |
| Compression | H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Video output | Composite video output (for debugging only) |
| Lens | Motorized varifocal 8~32 mm F1.7 DC-IRIS Autofocus |
| Viewing Angle (FOV) | H: 113.5~39°, V: 58.4~22.7°, D: 141.3°~44.3° |
| Minimum illumination | Colour: 0.001 Lux @ (F1.2, AGC ON)Black and White: 0 Lux with Infrared |
| Infrared lighting | IR LEDs range 50 m |
| Shutter time | 1~1/100,000 s |
| Day / Night | Removable mechanical ICR filter |
| Image improvements | WDR (140 dB), BLC, HLC, 3D-DNR, AGC, AWB |
| Motion Detection | Yes |
| License plate recognition | Detection until in 1 laneClassification of vehicles, color, vehicles without license plates, driving directionPlate recognition rate ?98%Capture range accuracy > 99%Direction recognition accuracy > |
| Intelligent traffic function | Vehicle color: Red, yellow, blue, pink, purple, cyan, brown, white, gray and blackType of vehicle: Car, Van, Bus, Truck, Light Truck, SUV, Pickup, Motorcycle and TricycleBrands: Up to 84 manufacturers |
| Speed radar | Detection distance: 20 - 50 mVelocity range: 10 - 100Km/hHorizontal angle: ± 22°Vertical angle: ± 10°Detection accuracy: ± 2Km/h |
| Alarms | 1 inputs / 1 relay |
| Audio | 1 Input / 1 Output |
| Audio type | Mono |
| Audio Compression | G.711/G.722.1 |
| Audio bit rate | 8 Kbps (G.711)/16 Kbps (G.722.1) |
| Internal memory | Slot for micro SD card up to 512 GB |
| Network interface | Ethernet 10/100/1000M BaseT |
| Communication | 1 x RS-485 / Wiegand |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Operating system | Linux |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 - 24V / 1250 mA / 15 W max. / PoE+ IEEE802.3at |
| Degree of protection | Weatherproof IP67 |
| Material | Aluminium alloy |
| Temp. operation | -30o C ~ +70o C |
| Dimensions | 184.4 (H) x 115.5 (W) x 298.6 (D) mm |
| Weight | 3000 g |
