| Brand | Hikvision |
| Range | PRO |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 Channels BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 16 Additional IP CH: Up to 32 IP channels (8 Mpx), replacing all BNC channels |
| Video outputs | 1 HDMI 4K and 1 VGA, simultaneous; 1 BNC CVBS |
| Display resolution | HDMI: 4K (3840x2160), 2K (2560x1440), 1920x1080, 1280x1024, 1280x720 / 60HzVGA: 1920x1080, 1280x1024, 1280x720 / 60HzCVBS: 704x576 (PAL) / 704x480 (NTSC) |
| Audio inputs | 4 RCA channels16 coaxial audio channels |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input |
| Audio bit rate | 64 Kbps |
| Audio Compression | G.711u |
| Video compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Input resolution | HDTVI: 8Mpx @ 12FPS, 3K (5Mpx 16 [%VAR%] [%VAR%]:9)@25FPS, 5Mpx @20FPS, 4Mpx @25FPS, 1080p@25FPS, 720p@25FPSHDCVI: 8Mpx @ 12FPS, 3K (5Mpx 16:9)@25FPS, 5Mpx @20FPS, 4Mpx @25FPS, 1080p@25FPS, 720p@25FPS |
| Main Stream coding | 8Mpx@8 FPS; 3K@12 FPS, 5Mpx@12 FPS; 4Mpx @15 FPS; 8Mpx Lite@15 FPS; 3Mpx@18 FPS; 1080p /720p/WD1/4CIF/VGA/CIF@25 FPS(P) |
| Extra Stream coding | WD1 / 4CIF / CIF (25 FPS) |
| Video Bit Rate | 32 Kbps at 10 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Motion Detection | Motion detection 2.0 with classification of humans and vehicles applied in motion detectionAvailable on all analog channels |
| AcuSense | Acusense: Perimeter protection based on VCA rules with false alarm filter for human and vehicle detection applied on: Line Crossing, Area Intrusion.Available in up to 8 analog video channels.* Motion |
| Facial Recognition | Up to 16 facial libraries;Up to 4 cameras for image comparison alarm (HD analog camera) |
| Facial Detection | Face detection; photo search;Up to 4 channels to capture image. |
| Alarms | 4 inputs/ 1 outputs |
| Recording method | Manual, programmed, motion detection |
| Internal memory | 2 SATA HDD 3.5" of up to 12 TB each (not included) |
| Communication | 2 x USB 3.0 (rear panel) / 1 x USB 2.0 (front panel) / RS-485 / RJ45 (Ethernet) |
| Remote connections | 128 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | AC 100~240 V, ? 20 W (without HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions | 384(W) x 313(D) x 52(H) mm |
| Weight | ? 2.1 Kg (without HDD) |
