| Brand | Hikvision |
| Range | Value |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 2 Additional IP CH: Up to 18 IP channels (6 Mpx), replacing all BNC channelsEnhanced IP Mode:8 Additional CH IPs: Up to 24 IP (6 Mpx channels), replacing all BNC channels |
| Available bandwidth | Total: 128 MbpsIncoming bandwidth: 96 Mbps |
| Video outputs | 1 HDMI 4K and 1 VGA, simultaneous; |
| Display resolution | HDMI: 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720VGA: 1920x1080, 1280x1024, 1280x720 |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input |
| Audio bit rate | 64 Kbps |
| Audio Compression | G.711u |
| Video compression | Analog channels: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264IP channels: H.265+ / H.265 / H.264+ / H.264 |
| Recording resolution | When 1080P Lite mode is not enabled:3K Lite / 5Mpx Lite / 4Mpx Lite / 1080p / 720p / WD1 / 4CIF / VGA / CIFWhen 1080P Lite mode is enabled:3K Lite / 5Mpx Lite / 4Mpx Lite / 1080p Lite / 720p Lite / WD |
| Input resolution | HDTVI: 3K (20 fps), 5MPx (20 fps), 4 Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~60 fps)HDCVI: 5MPx (20 fps), 4Mpx, 1080p (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps)AHD: 5MPx (20 fps), 4Mpx (25~ |
| Main Stream coding | 1080P Lite not enabled:For the 3K stream: 3K Lite (12 fps), 4 Mpx lite/1080p (15 fps), 720p/VGA/WD1/4CIF/VGA/CIF (20 fps)For the 5 Mpx stream: 5 Mpx Lite (12 fps), 4 Mpx Lite/1080p (15 fps), 720 |
| Extra Stream coding | WD1/4CIF (12 fps), CIF (25 fps (P), 30 fps (N)) |
| Video Bit Rate | 32 Kbps at 6 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection.Available on all analog channels.* Motion detection and AcuSense cannot be enabled at the same time on the same d |
| Intelligent functions | AcuSense DeepLearning based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Inbound Region, Outbound Region, Outbound RegionAvai |
| Face detection | Face detection, face search |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 1 SATA HDD 3.5" of up to 10 TB (not included) |
| Communication | 2 x USB 2.0 (rear side) / 1xRJ45 (Ethernet) |
| Remote connections | 128 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | DC 12 V, 1.9 A, ? 15 W (no HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions / weight | 45 (H) mm x 285 (W) mm x 210 (D) mm / ? 1 Kg (w/o HDD) |
| Colour | White |
