| Brand | Hikvision |
| Range | SOLUTIONS |
| Image sensor | 1/1.8" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Main Stream rate | Monitoring mode:Up to 50 fps (2688x1520, 2560x1440, 1280x720)Up to 100 fps (1920x1080)25 fps (2688x1520, 2560x1440, 1920x1080, 1280x720) [%VAR%] |
| Extra Stream rate | 25 fps (1280x720, 704×576, 640×480) |
| Third stream rate | 25 fps (1920×1080, 1280×720, 704×576, 640×480) [%VAR%] |
| Fourth Stream | 25 fps (1280x720, 704×576, 640×480) |
| Fifth Stream | 25 fps (1280x720, 704×576, 640×480) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Video output | Composite video output (for debugging only) |
| Lens | Motorized varifocal 2.8~12 mm |
| Viewing Angle (FOV) | H: 106~41.8°, V: 55.4~23.6°, D: 130°~48.1° |
| Range performance | 151.7~64.7 m (D), 60.2~25.7 m (O), 30.3~12.9 m (R), 15.2~6.5 m (I) |
| Minimum illumination | Colour: 0.0005 Lux @ (F1.2, AGC ON)Black and White: 0 Lux with Infrared |
| Supplementary lighting | Hybrid light:IR Range 100 mWhite light range 100 m |
| Shutter time | 1 s to 1/100,000 s |
| Day / Night | Removable mechanical ICR filterBlue glass module to reduce ghosting |
| Image improvements | WDR (140 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI (4 regions per each stream), Mirror function, Privacy masking |
| ANR | Yes |
| EIS (Image Stabilizer) | Yes |
| Vibration sensor | Yes |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. |
| AcuSense | DeepLearning based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Inbound Region, Outbound Region, Outbound Region |
| Alarms | 2 inputs / 2 outputs |
| Audio | 1 input / 1 output2 built-in microphones and speaker |
| Audio type | Mono |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio bit rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Ambient noise filtering | Yes |
| Internal memory | Slot for micro SD card up to 1TB |
| Network interface | Ethernet 10/100/1000M BaseT |
| Communication | 1 x RS-485 (half duplex) |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF (Profile S, G, T, M), ISAPI, SDK |
| Power | DC 12 V / 1800 mA / 21.5 W max.AC 24 V / 1470 mA / 21 W max.PoE+ IEEE802.3at / 23.1 W max. |
| Power supply output | DC 12 V / 100 mA |
| Degree of protection | Weatherproof IP67Anti-vandal IK10 |
| Corrosion protection | NEMA 4X (NEMA 250-2018) |
| Material | Aluminium alloy |
| Temp. operation | -40o C ~ +65o C |
| Heater | Yes |
| Dimensions | O 140 mm x 377.4 mm (D) |
| Base dimensions | O base 140 mm / O entre tornillos 96 mm / 4 tornillos |
| Weight | 2280 g |
