| Brand | IBOARD |
| Size (inches) | 86'' |
| Resolution | 3840x2160 (4K) @ 60Hz |
| Aspect ratio | 16:9 |
| Backlight | DLED |
| Brightness | 500 cd/m2 |
| Automatic brightness sensor | Yes |
| Contrast | 1200:1 |
| Angle of vision (H/V) | 178o (H/V) |
| Anti-reflective glass | 4mm |
| Touch technology | Infrared touch screen frame |
| Tactile precision | Opaque objects of < 2mm |
| Simultaneous touches | ? 20 (Android)? 50 (Windows) |
| Inputs | Fronts:1x HDMI 2.01x USB-C (Touch, data, audio, video and 15W charging)3x USB 3.01x USB-B (Touch)Rear:2x HDMI 2.01x VGA & AUDIO 1x DP1x USB-C (Touch, data, audio and video)3x UBS 3.01x Touch-USB1x |
| Outputs | 1x HDMI1x SPDIF (Optical)1x Headphones1x RJ45 |
| Front buttons | - On/Off (Power)- Source- Menu- Volume down (Vol - )- Volume up (Vol +)- Home- Enter- Panel shutdown (EN) |
| Operating system | Android 14.02xA76@1.9GHz + 2xA55@1.9GHzQuad-Core MaliG57 |
| Wi-Fi | WIFI 6, 5G/2.4G |
| Bluetooth | 5.2 |
| NFC | Compatible with iBoard NFC cards - Switching the interactive display on/off- User change |
| Ethernet | 10/100/1000M |
| RAM | 8G |
| Storage | 128G |
| Response time | 8ms |
| Wireless screen sharing | Yes, by using the application |
| Slate application | Drawview X |
| Speaker | 20W Speakers x2 + 20W Subwoofer x1 |
| Microphones | Array of 8 microphones |
| Thread for camera attachment | 1/4 female thread for camera |
| Minimal tactile target | < 2mm |
| VESA | 800x400 mm |
| Power | AC 100 V ~ 240 V, 50/60 Hz |
| Energy consumption | <1W (Standby)< 415W (Potencia nominal) |
| Dimensiones | 1954mm (An) x 1188mm (Al) x 85mm (Fo) |
| Peso | 68 kg |
An interactive display is a digital device with touch technology that allows direct interaction with its own software or with a PC (connected as a peripheral or through the use of an OPS), fostering collaboration, productivity and active user participation. These displays integrate advanced functionalities such as touch typing, real-time annotation tools and multi-device connectivity, making them a versatile and adaptable solution for a variety of needs.
They are used in different areas of the public and private sector, such as in education for dynamic classes, in companies for presentations and meetings, or in design for creative work, among others, which makes them a key tool for digital transformation.
