| Brand | Hikvision |
| Range | SOLUTIONS |
| Thermal sensor | Vanadium Oxide |
| Thermal sensor resolution | 256x192 |
| Optical sensor | 1/5” Progressive Scan CMOS |
| Optical sensor resolution | 2688x1520 |
| Main Stream rate | Thermal: 25 fps (1280x9600)Optic: 25 fps (2688x1520) |
| Extra Stream rate | Thermal: 25 fps (704x576)Optic: 25 fps (704x576) |
| Compression | H.265 / H.264 / MJPEG |
| Lens | 2.1 mm (Therm) / 1.4 mm (Opt) |
| Video bitrate | 256 Kbps ~ 16 Mbps |
| Minimum illumination | Colour: 0.06 Lux @(F2.2, AGC ON)0 Lux with IR |
| Viewing angle | Thermal: 90° (H), 64.2° (V)Optic: 96.9° (H), 77.2° (V) |
| VCA range | Temperature Measurement (Object 0.2x0.2m)): 7 mTemperature Measurement (Object 0.5x0.5m)): 17.5 m |
| Thermal sensitivity | < 40mK (0.05 o C) |
| Thermal measurement range | Two eligible modes:-20 ~150 oC / 0oC~550oC (± 2 oC) |
| Spectral range | 8~14 µm |
| Pitch detector | 12 µm |
| Temperature rules | Even 21 rules (10 points, 10 areas and 1 line) |
| Image improvements | 3D-DNR |
| Alarms | 2 outputs |
| Internal memory | Does not have |
| Network interface | Ethernet 10/100 BaseT |
| Communication | 1 x RS-485 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 V, 5 W max.PoE IEEE802.3af |
| Temp. operation | -20o C ~ +60o C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 111.2 mm (H) x 56 (W) x 38.9 (D) mm |
| Weight | 335 g |
