| Brand | Hongdian |
| Device | Industrial 4G Router |
| SIM | 2 SIM card slot 4G / 3G 2FF (not included) |
| Dual SIM | Auto Failover in case of low signal / data limit / roaming / no network |
| Serial Ports | Transparent, Modbus RTUDefinition of ports: RX, TX, GND (RS-232) , A+, B-, GND (RS-485)Connector 5-pin 3.5 mm female connectorTransmission rate RS-232 (300-115200bps), RS-485 (300-115200bps) |
| Wi-Fi | Wi-Fi 5 802.11ac Dual Band 2.4GHz+ 5GHz 2x2 MIMO |
| LTE | 2 x 4G LTE modules CAT 6 |
| 5G and LTE frequencies | 4G( LTE-FDD): B1/B3/B5/B7/B8/B204G (LTE-TDD): B38/B40/B413G(WCDMA): B1/B5/B82G: B3/B8 |
| Ethernet | 5 Ethernet ports RJ45 10/100/1000Mbps (1 WAN + 4 LAN) |
| Antenna connectors | WiFi and LTE (antennas included) |
| CPU | MIPS1004Kc 880 MHZ |
| RAM | 256MB DDR3 |
| Flash | 32MB |
| Network Protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, SSH, DDNS,APN, VPDN, VLAN, QoS, Static Routing, Policy routing, RIP, OSPF and BGP, Failover. |
| VPN Protocols | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard |
| Monitoring and Management | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP |
| Security | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List, DDOS prevention, Anti port scanning |
| Power | DC connector 5 Industrial pins 9~36V Power Supply Included |
| Electricity consumption | Inactive: 350mA@12vDCData Link: 900mA@12vDC |
| Material | Metallic |
| Degree of protection | IP30 |
| Temp. operation | -30o C ~ +75o C |
| Operating Humidity | ? 95%(no condensing) |
| Installation | Wall or tabletop |
| Dimensions | 28,5 (Al) x 177,8 (W) × 105,22 (D) mm |
| Weight | 550 g |
| Region | Europe, Middle East, Africa, Korea, Thailand, India, Malaysia, India, Malaysia |
