| Brand | Hongdian |
| Device | Industrial Router 4G PoE |
| Ethernet | 4 Ethernet ports RJ45 10/100 Mbps LAN or 3 × LAN + 1 × WAN |
| PoE | 1~4 IEEE 802.3af/at PoE portsTotal PoE power of 120W |
| SIM | 2 SIM card slots 4G / 3G 2FF (not included) |
| Positioning | Supported technologies: GPS, GLONASS, BeiDdou, GalileoProtocol: NMEA 0183Coordinates: WEB UI, RMS |
| Serial Ports | Definition of ports: RX, TX, GND (RS-232) , A+, B-, GND (RS-485)Connector 9-pin 3.5 mm female socketTransmission rate RS-232 (300-115200bps), RS-485 (300-115200bps) REVIEW |
| Wi-Fi | 1 x Wi-Fi RP SMA antennaWi-Fi 802.11b/g/n 2.4GHzSecurity WEP,WPA,WPA2Encryption 64/128 AES, TKIP |
| LTE Frequencies | Bands 4G 1/3/5/7/8/20/38/40/41 |
| Antenna connector | 2 x LTE SMA (Length 220 cm) (antenna included) |
| CPU | MIPS 24Kc 580MHZ |
| RAM | 128 MB |
| Flash | 16 MB |
| Network Protocols | PPP, PPPoE, TCP, UDP, IPv4, IPv6, DHCP, ICMP, NAT, HTTP, HTTPs, HTTPs, DNS, ARP, NTP, Telnet, SSH2, DDNS, APN, VPDN, VLAN, QoS, Static Routing, Policy routing, RIP, OSPF,BGP,Failover. |
| Monitoring and Management | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP |
| VPN Protocols | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard |
| Security | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List, DDOS prevention, Anti port scanning |
| Power | DC 9~54V 4 industrial pin connector (12V 1,5A power supply included) A 48v 2A power supply must be used to use the PoE/PoE+ functions |
| Material | Metallic |
| Degree of protection | IP30 |
| Temp. operation | -30o C ~ +70o C |
| Operating Humidity | 0 ~ 95 % (non-condensing) |
| Installation | DIN rail, wall or desktop |
| Dimensions | 36,6 (Al) x 147 (W) × 98 (D) mm |
| Weight | 480 g |
| Region | Europe, Middle East, Africa, Korea, Thailand, India, Malaysia, India, Malaysia |
