| Brand | Ajax Fibra |
| Certification NFA2P | Available |
| Security grade | Grade 3 |
| Communication protocols | Jeweller, Wings and Fiber |
| Internal security | Tamper-resistant opening |
| Internal siren | Does not have |
| Communication | Ethernet / Dual SIM 4G |
| Maximum devices | 100 wireless and wired (max. 10 between sirens and wireless and wired KeyPad TouchScreen) |
| Video integration | Up to 25 IP cameras or video recorder channels |
| Number or users | Up to 50 |
| Automation scenarios | 32 scenarios |
| Connection with CRA | Contact ID / SIA |
| Compatibility | Not compatible with ocBridge and uartBridge |
| Firmware Upgrade | Available. Remote OTA (Over-the-air) updates |
| Housing material | ABS plastic |
| Power | AC 110~250 V, 50/60 Hz |
| Backup battery | 12 V DC , 4~7 Ah (not included) |
| Backup battery life | Up to 60 hours (30 Fiber and battery 12V DC devices, 7 Ah) |
| Temp. operation | -10o C ~ +40o C |
| Dimensions | 192 (W) × 238 (H)× 100 (F) mm |
| Colour | White |
| Communication technology | Jeweller and Wings |
| RF frequency | 868 MHz |
| Jeweller Scope | Up to 2000 m in open space |
| Wings Scope | Up to 1700 m in open space |
| Communication technology | Fiber |
| Wired range | Up to 2000 m (Recommended): twisted pair U/UTP cat. 5) |
| Inputs | 8 independent bus lines |
| Bus connection | 4 wires (2 power and 2 data) |
| Connection topologies | Bus, star and ring |
| Fibra device power supply | 24 V DC (included on plate) |
| Functions | Armed, disarmed, partially armed and emergency |
| Bus connection | 4 wire cable |
| Transmission distance | Up to 2000 m (Recommended): twisted pair U/UTP cat. 5) |
| Codes | Up to 49 personal and 1 general |
| Power | 24 V DC (Consumption up to 400 µA) |
| Maximum consumption | 230 mW |
| Temp. operation | From -10o C to +40o C |
| Dimensions | 150 (H) x 103 (W) x 19 (D) mm |
| Bus connection | 4 wire cable |
| Wired inputs | Up to 18 inputs |
| Operating mode | Alarms or change arming modes |
| Types of events | Intrusion, Fire, Medical aid, Panic button, Gas alarm, Tamper alarm, Malfunction, Flood, Glass breakage, High temperature, Low temperature, Masking, Duress code (opening), Vibration (seismic sensor), |
| Tamper input | NC: Normally Closed |
| Alarm inputs | NO, NC, EOL, 2EOL, 3EOL / Impulse or bistable |
| End-of-line resistor EOL | From 1 k? to 15 k? with increments of 100 ? |
| Cable length | Up to 400 meters |
| Tamper-resistant opening | Front and back |
| Power supply output | Two outputs 12 V / 1 A (in total) for wired sensors |
| Compatibility | Compatible with Hub Hybrid (2G and 4G) |
| Power | AC 110~240 V, 50/60 Hz |
| Maximum consumption | 360 mW |
| Backup battery | Battery 12 V / up to 7 Ah (not included) |
| Advanced features | KeyArm Zone |
| Temp. operation | -10 oC ~ 40 oC |
| Dimensions of the backup battery | 150 (H) x 64 (W) x 94 (D) mm |
| Dimensions | 238 (H) x 192 (W) x 100 (D) mm |
