| Brand | EZVIZ |
| Inputs for IP cameras | LAN or WiFi port up to 16 channels |
| Communication via WiFi | 4 external antennas / Dual 2.4 band and 5 GHz with 100m an open field rangeDual link as access point for cameras and as client for WiFi router |
| Video compression format | H.265 |
| Maximum resolution | 5 Mpx |
| Decoding capacity | 16 x 5 Mpx |
| Power over Ethernet | Does not have |
| IP compatible cameras | EZVIZ (native protocol), ONVIF |
| Bidirectional audio | 1 input / 1 RCA output |
| Video outputs | 1 HDMI 2K, 1 VGA 1080p |
| Total bandwidth | 200 Mbps |
| Main stream recording | 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Recording method | Manual, programmed, motion detection |
| External Backup | USB / HDD USB memory |
| Internal memory | 1 SATA HDD 3.5" of up to 8 TB (not included) |
| Communication | 2 x USB 2.0 / 1 x RJ45 Gigabit (Ethernet) |
| Remote access | Web Browser, EZVIZ Smartphone App |
| Power | DC 12V / 3A |
| Dimensions / weight | 44.5 (H) x 270 (W) x 235 (D) mm / 1 Kg |
