| Model | PAVA9500 |
| Type | Fire emergency system with amplifier |
| Certification | UNE-EN 54-16 |
| Nominal power | 500 W (100V) |
| Power | 220~240V AC @ 50/60 Hz |
| Ports | 1 x Backup DC24V input8 x Speaker outputs 1 x EMC MIC2 x MIC4 x LINE IN1 x LINE OUT1 x EMC LINE OUT |
| Sensitivity (input signal) | - EMC MIC: 20mV 600?- MIC: 5±0.5mV 10k?- LINE: 1000±100mV 10k? |
| Harmonic Distortion | - EMC MIC: <1% 1kHz- MIC: 1%1khz- LINE: <1% 1kHz |
| Respuesta en frecuencia | - EMC MIC: 80Hz-15kHz (±3dB)- MIC: 1%1kHz- LINE: 50Hz-18kHz (±3dB) |
| Relación senal a ruido | - EMC MIC: >75dBA- MIC: 1%1kHz- LINE: >80dBA |
| Auxiliary EMC output | - Output voltage: 1000mV- Frequency range: 80Hz-15kHz (±3dB)- Harmonic distortion: <1% 1kHz |
| Sistema de control por contacto (entradas / salidas) | - Salida de relé de fallo del sistema: cortocircuito, sin voltaje- Salida de relé de modo de emergencia: cortocircuito, sin voltaje- Entrada de inicio de incendio: cortocircuito, t?0.5S, sin voltaje- |
| Mensaje de voz | Formato: WAV |
| Alimentación | - AC 220V ~ 240V @ 50/60Hz- DC 24V / 17A |
| Dimensiones | 428mm (An) x 88mm (Al) x 430mm (Pr) |
| Peso | 12.05kg |
All-in-one voice evacuation systems are designed to manage emergency communications, general announcements and background music in large buildings. It combines amplification, zone control and alarm management functions in a single unit, complying with EN54-16, standards, making it ideal for critical applications where public safety is a priority.
This type of system is used in facilities such as airports, hospitals, schools and shopping malls. Enables automatic or live messaging to different zones, real-time system status monitoring and integration with fire alarms and other security devices. Thanks to its modular design and expandability, it offers a flexible and reliable solution for audio management in both everyday and emergency situations.
