| Model | DP4004 |
| Signal processing | 32bit, 400MHz |
| Audio system delay | < 3ms |
| Digital-to-analog conversion | 24bit |
| Sampling frequency | 48kHz |
| Input channel | 4 balanced inputsMic/line level |
| Connector | 3.81mm Phoenix connector of 12-pin |
| Input impedance | 16k? |
| Maximum entry level | - Line: 17dBu (5.48Vrms)- Micro: -3dBu (0.54Vrms@20dB ganancia) |
| Phantom power | +48V DC (5.5mA per channel) |
| Output channel | 4 balanced outputsLine level |
| Output Impedance | 150? |
| Frequency response | - Line: 20Hz - 20kHz (±0.5dB) dBu (0.775Vrms)- Micro: 20Hz-20kHz (±1.5dB), 20dB gain, -10dBu (0.245Vrms) |
| Distortion | - Line: -90dB (@17dBu, 1kHz, A-wt)- Micro: -90dB (@-6dBu, 1kHz, A-wt), 20dB of gain |
| SNR (Signal to Noise Ratio) | - Line: 110dB (@17dBu, 1kHz, A-wt)- Micro: 100dB (@-6dBu, 1kHz, A-wt), 20dB of gain |
| USB | Type B 2.0 |
| RS232 | Communication port |
| TCP/IP network port | RJ-45 |
| Led indicator | Network, Phantom, active input and active output |
| Power | 90V ~ 264V AC @50&60Hz |
| Working temperature | -20oC ~ 60oC |
| Dimensions | 483mm (W) x 44.5mm (H) x 265mm (D) |
| Weight | 3.3kg |
Audio processors are devices designed to manage, adjust and optimize sound signals in professional audio systems. Its main function is to improve audio quality by means of tools such as equalization, gain control, compression, delay and signal mixing.
This type of equipment is used in facilities such as auditoriums, conference rooms, theaters, temples and other spaces where precise sound control is required. Thanks to their configurability, they allow to adapt the audio system to the acoustic characteristics of the place, guaranteeing a clear, balanced and professional reproduction.
