| Brand | Hikvision |
| Range | PRO |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Main Stream rate | 25 fps (1920×1080, 1280×720) |
| Extra Stream rate | 25 fps (640x480, 640×360) |
| Third stream rate | 10 fps (1920x1080, 1280x720, 640x480, 640×360) [%VAR%]* Third stream is only supported under certain configurations |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 107°, V: 57°, D: 127° |
| Range performance | 44 m (D), 17 m (O), 9 m (R), 4 m (I) |
| Electronic Shutter | 1/3~1/100.000 s |
| Minimum illumination | Colour: 0.005 Lux @(F1.6, AGC ON)0 Lux with IR range 40 m |
| Day/Night | Removable mechanical ICR filter |
| Image improvements | WDR (120 dB), BLC, HLC, 3D-DNR, AWB, Mirror function, Privacy masking |
| ANR | Yes |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection.* Motion detection and AcuSense cannot be enabled at the same time on the same device. |
| Intelligent functions | AcuSense DeepLearning based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion* Motion detection and AcuSense cannot be enabled at t |
| Internal memory | MicroSD card slot up to 512 GB |
| Audio | Integrated microphone |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio bitrate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF (Profiles S, G, T), ISAPI, SDK, ISUP |
| Power | DC 12 V / 500 mA / 6 W max.PoE IEEE802.3af |
| Degree of protection | Weatherproof IP67 |
| Temp. operation | -30o C ~ +60o C |
| Material | Metallic |
| Dimensions | O 74.4 mm x 179.2 mm (D) |
| Base dimensions | O base 74.4 mm / O entre tornillos 55 mm / 3 tornillos |
| Weight | 500 g |
