| Brand | Avigilon |
| Model | OP-VID-PRO-RDR |
| Camera | 1/2.5" CMOS 5 Mpx with HDRIR for night visionField of view: 109o (H), 81o (V), 136o (D) |
| Identification modes | Mobile credentials: Bluetooth BLE and NFC (Android only)Card 13.56 MHz: MF DESFire EV3, MF DESFire and MFCard 125 kHz: HID, ProxCard, LenelProx |
| Outputs | Wiegand 26/34, buzzer for status indication, tamper |
| Compatibility | Avigilon AVI-OP-CR-SDC controllers |
| Power | Standard PoE IEEE802.3af |
| Degree of protection | Suitable for exterior IP65 |
| Temp. operation | -40 oC ~ +50 oC |
| Dimensions | 47 (W) x 156 (H) x 32 (D) mm |
| Weight | 287 g |
An access reader is used to identify users who want to access a system protected by an access controller. Transmits the credential information, with the controller deciding how to proceed.
This reader allows identification through cards or key fobs with 125 kHz EM RFID technology, 13.56 MHz MF and 13.56 MHz MF DESFire, Bluetooth and NFC.
The connection to the controllers is made through Wiegand or RS485. These protocols allow a secure connection in the outdoor installation with their IP65 grade.
