| Brand | Advanced |
| Voltage DC | Nominal Relay Switching current 24V (15~40V) |
| Average consumption | 120µA |
| LED Consumption (Max.) | 6mA@24VDC |
| Accepted plug in | Accepted plug in up to 2.5mm2 |
| End-of-line resistor (REOL) | 27Kohm |
| Alarm resistor (Rw) | 10Kohm |
| Relay Nominal Switching Current | 30VDC / 2A max. |
| Operating temperature range | -30oC ~ +70oC |
| Humidity (non condensing) | 95% RH |
| Dimensions | 52 x 75 x 28 mm (H x W x D) |
| Weight | 180g |
| IP protection | IP21C |
| Certification | EN 54-17 |
