ADV-20-VMMC100

Brand: ADVANCED

Šifra: ADV-20-VMMC100

GTIN: 8435325442013

46,17 EUR

Dostupno

Dostupnost Dostupno

Načini plaćanja: Pouzećem, online plaćanje po broju narudžbe, PayPal

Brand	Advanced
Voltage DC	Nominal Relay Switching current 24V (15~40V)
Average consumption	120µA
LED Consumption (Max.)	6mA@24VDC
Accepted plug in	Accepted plug in up to 2.5mm2
End-of-line resistor (REOL)	27Kohm
Relay Nominal Switching Current	30VDC / 2A max.
Operating temperature range	-30oC ~ +70oC
Humidity (non condensing)	95% RH
Dimensions	85 x 85 x 30 mm (H x W x D)
Weight	180g
IP protection	IP21C
Certification	EN 54-17

Advanced
Module of 1 supervised output
Loop powered
Short circuit isolators on each device according to the requirements of EN54-17
Ability to address automatically (via control panel) or manually via a portable programmer
Two-way digital testing
Connections are made using plug-in terminal blocks which will accept conductors up to 2.5mm2
