| Brand | Advanced |
| Voltage DC | Nominal Relay Switching current 24V (18~40V) |
| Average consumption | 500µA |
| LED Consumption (Max.) | 6mA@24VDC |
| Accepted plug in | Accepted plug in up to 2.5mm2 |
| End-of-line resistor (REOL) | 27Kohm |
| Alarm resistance (Rsw) | 10Kohm |
| Relay Nominal Switching Current | 30VDC / 2A max. |
| Monitoring voltage | 24VDC, 30VDC |
| Operating temperature range | -30oC ~ +70oC |
| Humidity (non condensing) | 85% RH |
| Dimensions | 210 x 170 x 65 mm (H x W x D) |
| Weight | 470g |
| IP protection | IP65 |
| Certification | EN 54-17 |
