| Brand | Advanced |
| Voltage DC | Nominal Relay Switching current 24V (15~40V) |
| Average consumption | 120µA |
| Standby current | 500µA |
| Power Up Time | 2 seconds |
| Zone End of line device | Capacitor (Ceol): 4.7µF |
| Conventional Zone Current Threshold | 6 to 20mA (alarm threshold 2.5 to 15mA) |
| Relay Nominal Switching Current | 30VDC / 2A max. |
| Operating temperature range | -30oC ~ +70oC |
| Humidity (non condensing) | 95% RH |
| Dimensions | 93 x 130 x 58 mm (H x W x D) |
| Weight | 190g |
| IP protection | IP54 |
| Certification | EN 54-17 |
