| Detection range | 500m outdoor |
| Number of beams | 3 |
| Detection method | Configurable: alarm by cutting one beam, two beams or all beams at once |
| Sensitivity | Adjustable (50/100/300/700 ms) |
| Frequency channels | Each beam works at its own frequency |
| Alarm outputs | 1 relay NO/NC (max. AC125V/0.5A, DC24V/1A) |
| Alignment angle | H: ±15o / V: ±15o |
| Adjustment method | Through LED and alignment tool (ABL-JYD) |
| Operating temperature | -25oC ~ +70oC |
| Degree of protection | IP67 |
| Power | 12~24 VDC/VAC, 150 mA max. |
| MTBF | 120.000 hours |
| Dimensions | 66.7 (H) x 39 (W) x 25.3 (D) mm |
